1. All electrical specifications are referenced to 25°C ± 5°C ambient.
2. The inductance is measured at 100kHz, 0.25Vrms, 0 ADC.
3. DCR measured on a micro-ohmmeter.
4. Isat, saturation current, means DC current at 25°C that causes an inductance drop from its value without current.
5. Irms, temperature rise current, means DC current at 25°C that causes a temperature rise of 40°C approx.
    Temperature rise is highly dependent on many factors including PCB land pattern, trace size, and proximity to other components.
    Therefore temperature rise should be verified in application conditions.
6. For automotive products, add a"-Q" suffix to the part number, such as"CSC2213-1R0M-Q".
